| Parameter | Value |
|---|---|
| Main Drive Method | Linear Asynchronous Motor |
| Cart Belt Drive Method | Brushless DC Motorized Roller |
| Power Transfer to Carts | Sliding Contact (Carbon Brush) or Non-contact (High-frequency Induction) |
| Load/Unload Signal Activation | Leaky Feeder Cable Communication |
| Cart Belt Width | 480 mm |
| Cart Dimensions (Pitch × Width) | 600 × 700 mm |
| Applicable Weight Range | 0.1 kg ~ 35 kg |
| Applicable Dimensions Range | 150 × 150 × 5 mm ~ 600 × 400 × 400 mm (L × W × H) |
| Compatible Product Types | Various small items (e.g., food, cosmetics, garments) |
| Induction Method | Automatic / Manual |
| Operating Speed | 1.8 ~ 2.5 m/s |
| Sorting Efficiency | ≥ 10,000 pcs/h (with 1 set - 6 induction stations) ≥ 20,000 pcs/h (with 2 sets - 12 induction stations) |
| System Availability | > 99.5% |
| Average Noise Level | < 72 dB |
| Sorting Error Rate | ≤ 0.01% |
| Product Damage Rate | ≤ 0.01% |
| Barcode Read Rate | ≥ 99% (requires barcode grade B or higher) |
| Maintenance | Automatic lock failed cart, no need to stop the whole system which will impact the operation |
| Invention Patent | 39 |
| Utility Model Patents | 117 |
| Design Patent | 5 |
